Remote Control Commands

R&S

SMB100A

379Operating Manual 1407.0806.32 ─ 21

Parameters:

<State> 0 | 1 | OFF | ON

*RST: 0

Example:

POW:EMF:STAT 1

activates voltage level display.

Manual operation: See "Display Level as Voltage of EMF - RF Level" on page 151

[:SOURce<hw>]:POWer[:LEVel][:IMMediate][:AMPLitude] <Amplitude>

Sets the RF level applied to the DUT.

Notes:

If specified, a level offset [:SOURce<hw>]:POWer[:LEVel][:IMMediate]:

OFFSet is included according to the formula:

Minimum level + OFFSet ... Maximum level + OFFSet

In addition to numerical values, you can increase or decrease the values step by step

with the UP and DOWN according to the step width defined with [:SOURce<hw>]:

POWer:STEP[:INCRement].

The RF output is activated with :OUTPut<hw>[:STATe] on page 314 (RF ON / RF

OFF).

Parameters:

<Amplitude> Minimum level ... Maximum level

Determines the RF output level.

Range: Minimum level to Maximum level

*RST: -30

Example: The keywords of this command are largely optional. Therefore,

both the long and short form of the command are shown.

SOUR:POW:LEV:IMM:AMPL 15

:POW 15

sets the RF level at output A to 15 dBm.

Manual operation: See "RF Level" on page 146

[:SOURce<hw>]:POWer[:LEVel][:IMMediate]:OFFSet <Offset>

Note: The level offset is also effective for level sweeps!

Specifies the constant level offset of a downstream attenuator/amplifier. If a level offset

is entered, the level entered with :POWer no longer corresponds to the RF output

level.

The following correlation applies:

POWer = RF output level + POWer:OFFSet.

SOURce Subsystem
