Instrument Function
R&S
®
SMB100A
165Operating Manual 1407.0806.32 ─ 21
To select the sensor and determine its parameters, refer to Chapter 5.3.6.1, "NRP-Z
Power Viewer", on page 166.
To fill the table, press the "Execute" button.
Fill User Correction Data with Sensor
Enables you to fill the table with correction data acquired by a connected power sensor
from Rohde & Schwarz.
"Sensor"
Displays connected sensors for selection.
"List To Fill"
Indicates the used list file.
"Include Zeroing"
Performs a zeroing procedure before acquiring the user correction
data to improve precision. Since during zeroing no signal may be
applied to the sensor, RF is temporarily switched off at the generator.
When unchecked, the zeroing procedure is skipped. The RF signal
level might be blanked shortly. This setting is recommended if blank-
ing of RF is undesirable or the absence of power at the sensor can
not be guaranteed.
"Execute"
Performs automatic filling of the list, provided a sensor is detected
and the user correction list contains at least one frequency value.
Remote command:
[:SOURce<hw>]:CORRection:ZERoing:STATe on page 336
[:SOURce<hw>]:CORRection:CSET:DATA[:SENSor<ch>][:POWer]:SONCe
on page 331
Used SMB Settings for Measurement
Displays the settings relevant for the measurement.
"RF Source"
Shows the path for which the correction menu settings are made.
"Modulation"
Indicates the modulation state
"Amplitude"
Shows the currently set level.
"Use SParameter"
Indicates whether SParameter correction is used.
"Attenuator Mode"
Displays the selected mode of the attenuator.
"Fixed Range (PEP) In:"
Shows the level range.
Remote command:
n.a.
5.3.5.7 Reverse Power Protection
The reverse power protection prevents against overload by an external signal applied
to the RF output of the R&S SMB.
RF Block
