R&S SMB100A User Manual

Remote Control Commands
R&S
®
SMB100A
331Operating Manual 1407.0806.32 ─ 21
[:SOURce<hw>]:CORRection:CSET:DATA:POWer:POINts?
Queries the number of level values in the selected table.
The numerical suffix at SOURce must not be used for this command.
Return values:
<Points> integer
Range: 0 to 10000
*RST: 0
Example:
CORR:CSET '/var/user/ucor1'
selects the table ucor1.
CORR:CSET:DATA:POW:POIN?
queries the number of level values in the table ucor1.
Response: 440
the table ucor1 contains 440 level values.
Usage: Query only
[:SOURce<hw>]:CORRection:CSET:DATA[:SENSor<ch>][:POWer]:SONCe
The command fills the selected user correction list with the level values measured by
the power sensor for the given frequencies.
To select the used power sensor set the suffix in key word SENSe.
Example:
CORR:CSET:DATA:SENS:POW:SONC
fills the user correction list with level values acquired by the
power sensor connector to the SENSOR connector.
Usage: Event
Manual operation: See "Fill User Correction Data with Sensor" on page 165
[:SOURce]:CORRection:CSET:DELete <Filename>
Deletes the specified table.
The lists are stored with the fixed file extensions *.uco in a directory of the user's
choice. The directory applicable to the commands is defined with the command
MMEMory:CDIR. A path can also be specified in command SOUR:CORR:CSET:CAT?,
in which case the file in the specified directory is deleted.
Setting parameters:
<Filename> <table name>
Example:
MMEM:CDIR '/var/user/ucor'
selects the directory for the user correction files.
CORR:CSET:DEL 'UCOR1'
deletes the table ucor1.
Usage: Setting only
Manual operation: See "User Cor. Data - User Correction" on page 159
SOURce Subsystem
