RFL Electronics IMUX 2000 - Page 334

Because RFL™ and Hubbell® have a policy of continuous product improvement, we reserve the right to change designs and specifications without notice.
RFL DA-291B RFL Electronics Inc.
April 13, 2010 14 (973) 334-3100
Table 8. Data Port Configuration (baud rate)
SWITCH SETTINGS
Set the appropriate channel (1-4)
CH1
CH2
CH3
CH4
SW6-1
SW7-1
SW8-1
SW9-1
SW6-2
SW7-2
SW8-2
SW9-2
SW6-3
SW7-3
SW8-3
SW9-3
Maximum
Data Rate
Number Of
Time Slots
ON ON OFF 38.4 kbps 1
ON OFF ON 19.2 kbps 1/2
ON OFF OFF 9.6kbps 1/4
OFF ON ON 4.8 kbps 1/8
OFF ON OFF 2.4 kbps 1/8
OFF OFF ON 1.2 kbps 1/8
OFF OFF OFF 0.6 kbps 1/8
Table 9. Time Slot Start Bit
CHANNEL START BIT SETTINGS
Configure the appropriate channel (1-4)
CH1
CH2
CH3
CH4
SW6-4
SW7-4
SW8-4
SW9-4
SW6-5
SW7-5
SW8-5
SW9-5
SW6-6
SW7-6
SW8-6
SW9-6
Channel Start
Bit
OFF OFF OFF 0
OFF OFF ON 1
OFF ON OFF 2
OFF ON ON 3
ON OFF OFF 4
ON OFF ON 5
ON ON OFF 6
ON ON ON 7
Table 10. Bits per Character
BITS PER CHARACTER
Configure the appropriate
channel (1-4)
CH1
CH2
CH3
CH4
SW6-7
SW7-7
SW8-7
SW9-7
SW6-8
SW7-8
SW8-8
SW9-8
Bits per
character
OFF OFF 9
OFF ON 10
ON OFF 11
