NOTE
The RFL OCUDP Module can be operated in local or remote control mode. In local-control
mode its configuration is determined by on-board DIP-switches.
Under remote control, the switch positions are ignored and the module is remotely configured
by the user, using terminal or Network Management Systems. Presetting local-control
switches is not required for remote-control mode. If local-control switches are not preset, the
channel module will not operate correctly until remotely configured.
The only configuration switches that must be set for remote-control mode are those for the
SCB address (SW1-3 through SW1-8).
If you are planning to operate the RFL OCUDP Module under local control, continue to Step 7. on
page 10 to set the positions of the on-board DIP-switches.
Although remote control mode does not require it, RFL recommends setting local-control switches to
the required configuration at this time. Doing this allows the Common Module to discover the desired
settings and activate the channel module during initial commissioning, without the need for remote
access by the user or Network Management System. This also enhances operation reliability by
providing a configuration backup in case of NMS file loss or equipment failure.
If you do not intend to preset local-control switches for remote-control mode, go to Step 15 on
page 11.
The following pages show the location of the various configuration DIP switches and LED indicators
on the OCUDP board with an explanation of their function.
