Note 5
Continued.
Tables 6 & 7 are used to determine valid address selections when MTS modules with Actel versions 4 or lower
are connected to modules with Actel versions 5 or higher. Both Tables are utilized; each of them pertains to one
direction of the line.
Table 6. Tx address for Actel version 4 or earlier and Rx address for Actel version 5 or later
RFL DS-TT RFL Electronics Inc.
January 31, 2008 25 (973)
334-3100
Required Tx and Rx Address settings for systems
using different versions of DSTT modules
Transmit Address
(Transmitting MTS
with ACTEL Version
SW2000TTTR4 or
lower)
Receive Address
(Receiving MTS with
ACTEL Version
SW2000TTTR5 or
higher)
0 0
32 32
1 1
33 33
2 2
34 34
3 3
35 35
4 4
36 36
5 5
37 37
6 6
38 38
7 7
39 39
Invalid Invalid
Invali
d Invalid
Invalid Invalid
Invali
d Invalid
Invalid Invalid
Invali
d Invalid
Invalid Invalid
Invali
d Invalid
Invalid Invalid
Invali
d Invalid
Invalid Invalid
Invali
d Invalid
Invalid Invalid
Invali
d Invalid
Invalid Invalid
Invali
d Invalid
16 16
48 48
17 17
49 49
18 18
50 50
19 19
51 51
20 20
52 52
21 21
53 53
22 22
54 54
23 23
55 55
Invalid Invalid
Invali
d Invalid
Invalid Invalid
Invali
d Invalid
Invalid Invalid
Invali
d Invalid
Invalid Invalid
Invali
d Invalid
Invalid Invalid
Invali
d Invalid
Invalid Invalid
Invali
d Invalid
Invalid Invalid
Invali
d Invalid
Invalid Invalid
Invali
d Invalid
>> Note 5 continues on next page <<
