Note 5
continued.
Table 7. Tx address for Actel version 5 or later and Rx address for Actel version 4 or earlier
Required Tx and Rx Address settings for systems
using different versions of DSTT modules
Transmit Address
(Transmitting MTS
with ACTEL Version
SW2000TTTR5 or
higher)
Receive Address
(Receiving MTS with
ACTEL Version
SW2000TTTR4 or
lower)
Invalid Invalid
Invalid Invalid
Invalid Invalid
Invalid Invalid
Invalid Invalid
Invalid Invalid
Invalid Invalid
Invalid Invalid
Invalid Invalid
Invalid Invalid
Invalid Invalid
Invalid Invalid
Invalid Invalid
Invalid Invalid
Invalid Invalid
Invalid Invalid
8 0
40 32
9 1
41 33
10 2
42 34
11 3
43 35
12 4
44 36
13 5
45 37
14 6
46 38
15 7
47 39
Invalid Invalid
Invalid Invalid
Invalid Invalid
Invalid Invalid
Invalid Invalid
Invalid Invalid
Invalid Invalid
Invalid Invalid
Invalid Invalid
Invalid Invalid
Invalid Invalid
Invalid Invalid
Invalid Invalid
Invalid Invalid
Invalid Invalid
Invalid Invalid
24 16
56 48
25 17
57 49
26 18
58 50
27 19
59 51
28 20
60 52
29 21
61 53
30 22
62 54
31 23
63 55
