RFL Status Module RFL Electronics Inc.
July 15, 2007 17 (973)
334-3100
“S” CODES
“S” codes appear in response to a “STATUS?” query. There are three “S” codes for the Status
Module. Like the “P” codes, each “S” code is a number displayed in both decimal and binary
form.
A typical response to a “STATUS?” query looks like this:
*OK
FROM NET ADDRESS = 9
CHANNEL CARD 10, TYPE 120
S01 = 0 (B00000000)
S02 = 0 (B00000000)
S03 = 3 (B00000011)
S04 = 0 (B00000000);
These codes provide information on the status of several conditions on the Status Module. Table 4
lists the meaning of all “S” codes for the Status Module.
Table 4. Remote status messages (“S” codes)
Code Bits
Used Value Description
S01 B 00000000 0 Point 1 status inactive
↑↑↑↑↑ ↑
1 Point 1 status active
B 00000000 0 Point 2 status inactive
↑
1 Point 2 status active
B 00000000 0 Point 3 status inactive
↑
1 Point 3 status active
B 00000000 0 Point 4 status inactive
↑
1 Point 4 status active
B 00000000 0 Point 5 status inactive
↑
1 Point 5 status active
B 00000000 0 Point 6 status inactive
↑
1 Point 6 status active
B 00000000 0 Point 7 status inactive
↑
1 Point 7 status active
B 00000000 0 Point 8 status inactive
↑
1 Point 8 status active
<< table continues on next page >>
