RFL Status Module RFL Electronics Inc.
July 15, 2007 18 (973) 334-3100
Table 4 - continued. Remote status messages (“S” codes)
Code Bits Used Value Description
S02 B 00000000 0 Point 9 status inactive
↑↑↑↑
↑↑
1 Point 9 status active
B 00000000 0 Point 10 status inactive
↑
1 Point 10 status active
B 00000000 0 Point 11 status inactive
↑
1 Point 11 status active
B 00000000 0 Point 12 status inactive
↑
1 Point 12 status active
B 00000000 0 Point 13 status inactive
↑
1 Point 13 status active
B 00000000 0 Point 14 status inactive
↑
1 Point 14 status active
B 00000000 0 Point 15 status inactive
↑
1 Point 15 status active
B 00000000 0 Point 16 status inactive
↑
1 Point 16 status active
S03 B 00000000 0 Address invalid
↑
1 Address valid
B 00000000 0 Data invalid
↑
1 Data valid
B 00000000 0 Outputs locked (SW-2 Down)
↑
1 Outputs unlocked (SW-2 Up)
S04 B 00000000 0 Presently not used
