SERVICE PROGRAM MODE
B121 Series/B259 Series 5-46 SM
SSP
5834
Operation Panel Image Exposure [0: Off (disabled)/1: On (enabled)]
5834 1 Enables and disables the operation panel read (dump) feature. After powering on
the machine, set this option to 1 to enable this feature. To reset the machine to 0,
the machine must be turned off and on again. Selecting 0 for this option without
cycling the power off and on does not restore the default setting (0).
5839*
IEEE 1394
Host Name Enter name 5839 4
Enter the name of the device used on the network.
Example: RNP0000000000
Cycle Master OFF / ON 5839 7*
Enables or disables the cycle master function for the 1394 bus standard.
BCR mode 5839 8*
Determines how BCR (Broadcast Channel Register) operates on the 1394 standard
bus when the independent node is in any mode other than IRM. (NVRAM: 2bits)
Always Effective: Writes from the IRM.
Standard: Copies BCR of the IRM after no data is written from the IRM
after the prescribed time has elapsed.
IRM Color Copy: BCR normally enabled.
IRM 1394a Check 5839 9*
Conducts a 1394a check of IRM when the independent node is in any mode other
than IRM.
OFF: Checks whether IRM conforms to 1394a.
ON: After IRM is checked, if IRM does not conform then independent node
switches to IRM.
Unique ID 5839 10*
Lists the ID (Node_Unique_ID) assigned to the device by the system administrator.
OFF: Does not list the Node_Unique_ID assigned by the system administrator.
Instead, the Source_ID of the GASP header in the ARP is used.
ON: The Node_Unique_ID assigned by the system administrator is used, and the
Source_ID of the GASP header in the ARP is ignored. Also, when the serial
bus is reset, extra bus transactions are opened for enumeration.
Logout 5839 11*
Handles the login request of the login initiator for SBP-2. (1bit)
OFF: Disable (refuse login). Initiator retry during login. Login refusal on arrival of
login request (standard operation)
ON: Enable (force logout). Initiator retry during login. Login refusal on arrival of
login request, and the initiator forces the login.
Login 5839 12*
Enables or disables the exclusive login feature (SBP-2 related).
OFF: Disables. The exclusive login (LOGIN ORB exclusive it) is ignored.
ON: Enables. Exclusive login is in effect.
Login MAX [0~63 / 8 / 1], (0 and 63: Reserved) 5839 13*
Sets the maximum number of logins from the initiator (6-bits)
