Ricoh MT-P2 - Installation

Installation
1. Remove the left upper cover [1] ( x 2).
2. Disconnect the connector [2] from the machine and remove the cap.
3. Connect the sensor harness [3] to the sensor.
4. Attach the sensor bracket and actuator arm bracket [4] to the machine ( x 2).
1. Installation
108
1
