Service Program Mode Tables
Service Table Key
Notation What it means
[range/step]
Example: [–9~+9/0.1 mm]
The default setting can be adjusted in 0.1mm steps in the range ±9.
Italics Comments added for reference.
DFU Denotes “Design or Factory Use”. Do not change this value.
Japan Only The feature or item is for Japan only. Do not change this value.
SEF Short Edge Feed
LEF Long Edge Feed
NIA No Information Available (May 2006)
• In the first line of each table in this section, you will see the name of the SP code as it appears on the
screen (enclosed by square brackets) followed by the long title. For example "[Side-to-Side Reg]
Side-to-Side Registsration".
• If you see any refererences to "Bypass" or "Bypass Tray" in these SP tables or on the machine display,
please ignore them. This machine does not have a bypass tray.
Service Tables
SP1xxx Feed
1001 [Leading Edge Reg] Leading Edge Registration
Adjusts the printing leading edge registration using the trimming area pattern
(SP2902-003, No.18).
[–9~+9/0.1mm]
Specification: 3±2mm
5. Service Tables
314
