Ricoh MT-P2 - Ieee1284 B679

Installation
1. Remove the cover [A] of board Slot B1 ( x2).
2. Install the USB host interface board [B] in Slot B1 ( x2).
IEEE1284 B679
Accessory Check
Check the accessories and their quantities against this list:
Description Qty
1. IEEE 1284 Centronics Board 1
• If another card is installed in B2, you must remove it before installing this card.
MFP Options
115
1
