Ricoh MT-P2 - Finisher 2 Input Check: SP6122

6124 [Output C Fin 1]
015 Upper Junction Gate Solenoid
03
1
Exit Jogger Motor: Rear
016 Lower Junction Gate Solenoid
03
2
Exit Jogger Release Motor
Finisher 2 Input Check: SP6122
6122 [Inpput C Fin 2]
These are the input checks for the 3000-Sheet Finisher B706.
001 Entrance Sensor
02
1
Proof Full Sensor
002 Proof Exit Sensor
02
2
Stapler Moving HP Sensor
003 Shift Exit Sensor
02
3
Staple Waste Hopper Sensor
004 Staple Exit Sensor
02
4
Pre-Stack Tray HP Sensor
005 Tray Lower Sensor
02
5
Hold HP Sensor
006 Tray Near Lower Sensor
02
6
Exit Guide HP Sensor
007 Stack Feed Out HP Sensor
02
7
Stapler Reverse Sensor
008 Jogger HP Sensor
02
8
Stapler Sensor
009 Shift HP Sensor
02
9
Front Hold HP Sensor
010 Stapler Moving HP Sensor
03
0
Rear Hold HP Sensor
