Dimensions
Peripheral/Option Summary Table
The table below summarizes all the peripheral devices and controller options that can be installed with this
machine.
No. Name Class Comment
B475 A3/11"x17" Tray Unit Type 1075 1 Conversion kit for printer tandem tray.
B499 Tab Sheet Holder Type 3260 1 Installed by operator.
B473 LCT RT43 1
B756 Copy Tray Type 2075 1 Attached to printer if no peripherals in-
stalled downstream.
G845 LCT Connection Unit Type A 2 Raises height of LCT. Required for instal-
lation of LCT with this printer.
B474 8½" x 14" Paper Size Tray Type 1075 2 Conversion kit for LCT.
B704 Cover Interposer Type 3260 2 Installed on either B706 or B700
Installation Requirements
25
