Installation
The Punch Unit B531/A812 is installed in the 3000-Sheet Finisher B706.
• Switch the machine off and unplug the machine before starting the following procedure.
1. If the finisher is connected to the machine, disconnect it.
2. Open the front door and remove the rear cover ( x 2).
3. Unpack the punch unit and remove the motor protector plate [1] ( x 4) and the cam lock
plate [2] ( x 1).
Punch Unit (B531/A812)
73
