Duplex Sensors
Jogger HP Sensor
1. Duplex unit release lever [A] ( x 2)
2. Jogger HP sensor [B] (spring x 1, x 2, x 1)
Duplex Entrance Sensor
1. Bracket [A] ( x 2)
Duplex Unit
201
3
