4. Do not place the machine where it may be subjected to strong vibrations.
5. Do not connect the machine to a power source shared with another electrical appliance.
6. The machine can generate a an electromagnetic field which could interfere with radio or television
reception.
7. To avoid the possible accumulation of ozone, place the machine in an area that is well ventilated.
(The rate of air replacement should be more than 30 m
3
/hr/person.
Machine Level
Place the machine on a strong and level base. Level the machine to less than 5 mm (0.2") front to back.
Front to back: Less than 5 mm (0.2") of level
Right to left: Less than 5 mm (0.2") of level
The machine legs can be screwed up or down in order to level the machine.
Minimum Space Requirements
Place the machine near the power source with minimum clearance as shown below. The same amount of
clearance is necessary when optional peripheral devices are installed.
1. Installation
24
