6. Details

Overview

1. Fusing Unit

2. Development Unit

3. OPC Drum

4. Development Roller

5. Registration Sensor

6. Relay Sensor

7. Upper Relay Roller

13. Universal Tray (Tray 2)

14. Tandem Tray (Tray 1)

15. Duplex Unit

16. Inverter

17. Inverter Exit Roller

18. Inverter Entrance Roller

19. Duplex Junction Gate

435
