DIP Switch Tables
BCU (Base Engine Control Unit)
BCU Base Board DIP SW101
No. Function Default Comments
1 DFU OFF
2 DFU OFF
3 DFU OFF
4 Not used OFF
5 Not used OFF
6 Region Selection - Japan: 6, 7, 8/ OFF, OFF, OFF
7 Region Selection - NA (115V): 6, 7, 8/ ON, OFF, OFF
8 Region Selection - EU (220/240V): 6, 7, 8/ OFF, ON, OFF
DFU: Design, Factory Use only. Do not change these settings.
Controller Board
Controller Board DIP SW 4
No. Function Default Comments
1 Not used OFF
2 Boot mode ON
ON: Quick Boot, OFF: Normal Boot
Note: The boot time is longer when this switch is OFF
because the machine performs a full system check.
3 Not Used OFF
4 Not Used OFF
5 Boot Selection OFF Flash ROM Boot: 5, 6, 7/ OFF, OFF, OFF
6 Boot Selection OFF SD Card 1 Boot: 5, 6, 7/ OFF, ON, OFF
