7 Boot Selection OFF
SD Card 2 Boot: 5, 6, 7/ ON, ON, OFF
SD Card 3 Boot: 5, 6, 7/ OFF, OFF, ON
8 Not Used OFF
Controller Board DIP SW 5
No. Function Default Comments
1 DFU OFF
2 Not Used OFF
• DFU: Design, Factory Use only. Do not change these settings.
Controller Board DIP SW 6
No. Function Default Comments
1 Not Used OFF
2 Not Used OFF
3 Not Used OFF
4 Not Used OFF
DIP Switch Tables
425
