No. Test Pattern
25 [Trim Area Out] Trimming Area (with external data)
26 [Argyle Outs] Argyle Pattern (with external data)
27 [Outside Data] Outside Data
Updating the Firmware
SD cards are used to update the software and to back up important data. Here is a list of the firmware
modules that can be updated or restored from an SD card:
• GW controller software
• BCU software
• LCDC (operation panel) software
• Network Sys NIC (DESS/EU) software
• Web Sys (Web Image Monitor)
• NFA (Net File) software
• Printer application software
Here are some important points to remember when you use SD cards.
• Never connect or remove an SD card with the machine power turned on.
• Never turn the power off while the machine is downloading data from an SD card.
• SD cards are precision items. Store, handle, and use them carefully.
• Never store SD cards in a location where they are exposed to high temperature, high humidity, or
direct sunlight.
• Never bend an SD card, scratch it, or expose it to strong vibration.
• Before uploading data to an SD card, always confirm that its write-protect switch is off.
Doing the Software Update Procedure
1. An SD card with the software is necessary for this procedure.
2. Turn the main switch off.
5. Service Tables
306
