6125 [Output C Fin 2]
004
Proof Junction Gate Solenoid
01
7 Hold (Fold Plate) Motor
005
Shift Relay Motor
01
8 Pre-Stack Solenoid
006
Jogger Motor
01
9 Guide (Junction Gate) Solenoid
007
Stapler Moving Motor
02
0 Stapler Release Solenoid
008
Stapler Motor
02
1 Front Hold (Fold) Motor
009
Punch Motor
02
2 Rear Hold Motor
010
Stapler Solenoid
02
3 Reverse Drive Motor
011
Knock (Staple Hammer) Motor
02
4 Reverse Feed Motor
012
Stack Feed Out Motor
02
5 Exit Jogger Motor
013
Shift Motor
02
6 Exit Jog Release Motor
