1002 [Side-to-Side Reg] Side-to-Side Registration
Adjusts printing side-to-side registration for each feed station, using test pattern (SP2902-003,
No.18).
These SP’s should be adjusted after replacing the laser synchronization detector or the laser
optical unit.
001 Tray-1 [–9~+9/0.1 mm]
002 Tray-2
003 Tray-3
004 Tray-4 (Japan Only)
005 By-pass Tray (Not Used)
006 LCT
007 Duplex Tray
1003 [Regis Buc] Registration Buckle Adjustment
Adjusts the registration motor timing. This timing determines the amount of paper buckle at
registration. (A higher setting causes more buckling.)
[–9~+9/1 mm]
001 Tray
002 Duplex Tray
003 LCT
1008 [Duplex Fence Adj] Duplex Fence Adjustment
Adjusts the distance between front and rear fences. A smaller value shortens the distance. If
the fences are too far apart, skewing may occur in the duplex tray. If the fences are too close,
the paper may be creased in the duplex unit.
[–5~+5/0.1 mm]
1103 [Idling Time] Hot Roller Idling Time
This setting controls the length of time that the hot roller turns freely with no paper in the fusing
unit. This increases the temperature of the hot roller.
