1. If the machine is on, turn off the power switch.
2. Disconnect the network cable.
3. Turn the power switch on.
4. Turn the power switch off.
5. Remove the SD card slot cover [A] (x1).
6. With the printed side of the SD card [B] facing the rear of the machine, install the SD card in
SD card slot C2.
7. Reconnect the network cable, if the network is connected.
8. Turn the power switch on.
9. Do SP5878 and push [#Enter].
10. Go out of the SP mode and turn the power switch off.
11. Turn the machine power on with the SD card in SD card slot C2.
Checking the Installation
Do this procedure to confirm that the data overwrite security feature is enabled and operating.
1. Enter the SP mode and do SP5990 005 (Diagnostic Report) to print the Diagnostic Report.
2. Check the Diagnostic Report.
• Under "[ROM No. / Firmware Version]", you should see "B7355050/0.03" displayed for HDD
Format Option.
• Under "[ Loading Program ]" you should see "GW1a_zoffy: B7355050/0.03".
• The Data Overwrite Security SD card must remain in SD card slot C2.
• If the SD card is removed from C2 while the machine is operating, this will cause SC867
(SD Card Removed). Insert the SD card again and cycle the machine off/on.
• Detailed instructions for the operation of the Data Overwrite Security Unit are provided on
the CD-ROM provided with the SD card.
