(6): Vertical transport sensor OFF > Relay sensor does not switch OFF at the correct time.
(7): Relay sensor ON > Registration sensor does not switch ON at the correct time.
(8): Relay sensor OFF> Registration sensor does not switch OFF at the correct time.
(9): Registration motor ON > Fusing unit paper exit sensor does not switch ON at the correct time.
(10
):
Fusing unit paper exit sensor ON > Exit unit entrance sensor does not switch ON at the correct
time.
(11
):
Exit unit entrance sensor ON> Paper exit sensor does not switch ON at the correct time.
(12
):
Registration motor OFF > Paper exit sensor does not switch OFF at the correct time.
