Power Sources
Main Machine
Input voltage level
North America 120 V, 60 Hz: 20 A or more
Europe/Asia 220 V ~ 240 V, 50 Hz/60 Hz: 10
A or more
Permissible voltage fluctuation ±10%
LCT Ê Rating voltage of Output Connector: Max. DC 24V (from main machine)
Finisher Ë Rating voltage of Output Connector: Max. DC 24V (from main machine)
• Never turn off the power switch when the power LED is lit or flashing. To avoid damaging the hard
disk or memory, wait for the power LED to go off, and then switch the power switch off.
The Power LED lights or flashes:
• While the main machine is communicating with the network server
• While the machine is accessing the hard disk or memory when reading or writing data.
Installation Requirements
27
