7504 3000-Sheet Finisher (B706) Corner Stapling Only
141 Entrance Sensor
142 Upper Tray Exit
143 Shift Tray EXit
144 Staple Tray Exit
145 Transport Motors
148 Drive Motor
149 Tray Motor
150 Jogger Motor
151 Shift Tray Lift
153 Finisher 153. Stapler Unit
155 Staple Motor
156 Punch Motor
7504 Cover Interposer Tray (B704)
166 Inserter 1. Feed or Pull-out Sensor
When the paper fails to activate the feed or pull-out sensor at the precise time.
167 Inserter 2. Exit Sensor
When the paper fails to activate the exit sensor at the precise time or remains at the exit sensor
for longer than the prescribed time.
168 Inserter 3. Bottom Plate Position Sensor
When the status of the bottom plate position sensor does not change at the precise time during
bottom plate motor rotation. Returns SC750,
7506 [Jam Paper Size] Jam Count by Paper Size
Displays the total number of jams by paper size.
005 A4 LEF
Displays the total number of jams by paper size.
5. Service Tables
