5 Toner Overflow SW
Switch not press-
ed
Switch pressed
4 Toner Collection Bottle Set SW Switch pressed
Switch not press-
ed
3 Not used
2 Not used
1 Not used
0 Not used
10. Paper Feed 10 DFU
11. Paper Feed 11 DFU
12. DIP Switches DFU
13. Exit
Bit Description Reading
0 1
7 Toner Collection Motor Sensor Deactivated Activated
6 Toner End Sensor Toner end Not toner end
5 Toner Collection Coil Sensor Deactivated Activated
4 Not used
3 Exit Unit Set Set Not set
2 Paper Exit Sensor Paper present Paper not present
1 Exit Unit Entrance Sensor Paper present Paper not present
0 Web End Sensor Not web end Web end
14. Duplex
Bit Description Reading
