Drum Pick-off Mechanism
Pick-off pawls ride along the surface of the drum to peel off paper that has not separated from the drum.
Weak spring pressure [A] keeps the pick-off pawls [B] against the surface of the drum.
During copying, a shaft [C] turns a cam [D]. The cam moves the pick-off pawls from side to side to prevent
drum wear at any fixed location.
Drum Cleaning
