6. FASTENING SETTING mode (Type M)
6-14
Interlock information ( * )
If there is an interlock command in the fastening program for MULTI CONTROLLER, then the
interlock symbol “ * “ will be displayed automatically.
The interlock No. (from 01 to 32 ) shall be set if the symbol ( * ) is displayed as shown above.
If there is no interlock symbol ( * ) displayed, then input “0 “.
CAUTION
The interlock release sequence (from 01 to 32) setting is required if there are interlock commands
for the MULTI CONTROLLER in the fastening program.
If there is no interlock symbol ( * ), then “00 “ shall be set.
NOTE
1. The No. of interlocks must be identical for all spindles in the simultaneous fastening.
2. The interlock command for MULTI CONTROLLER is the interlock release signal via RS485
communication.
Example : The program with the interlock level 1 selected will be as follows.
60 02 00 01
Interlock level 1
External output data
Interlock for MULTI CONTROLLER
Interlock command code
To Next Page
