13. Specifications
13-2
13.1 Specifications
●DISPLAY PANEL SPECIFICATIONS
ITEM SPECIFICATION
MODEL SDN-DP06M SDN-DP06C SDN-DP06T
DISPLAY DEVICE STN monochrome STN color TFT color
COLOR 16-grade (with blinks)
65,536 colors (without blinks) / 32,768 colors (with
blinks) / 128 colors (with 16-color blinks)
DISPLAY RESOLUTION 320 x 240 dots
DIMENSIONS （mm） （W）182.5 x （H）138.8 x （D）74.4
WEIGHT Approx. 0.8 Kg
POWER CONSUMPTION Approx. 17 W
NR INTERFACE ARCNET
Ambient temperature From 0 to 50℃
Humidity 85%RH or less （non-condensing）
Storage temperature From -10 to +60℃
Storage humidity 85%RH or less （non-condensing）
Altitude 2000m or less
Vibration
Resistance
9.8 m/s
2
(1.0G)
Atmosphere No corrosive gas, no excessive dust, and no conductive dust
Cooling system Air cooling without blower
Input voltage DC24V (From 21.6V to 26.4V）
ENVIRONMENTAL CONDITIONS
Noise 1000Vp-p (normal mode, common mode)
Table 13.1-1 DISPLAY PANEL SPECIFICATION(SDN-DP06)
