3. Handling and configuration
3-2
3.1 Installing the DISPLAY PANEL
3.1.1 Power source of the DISPLAY PANEL
Use the power supply of the following specifications for the DISPLAY PANEL.
ITEM NAME SPECIFICATION
Input Voltage DC24V
Operating Voltage DC21.6〜26.4V
Power Consumption Approx. 17W
Table 3.1-1 Specifications of the power supply to the DISPLAY PANEL SDN-DP06
ITEM NAME SPECIFICATION
Input Voltage DC24V
Operating Voltage DC21.6〜26.4V
Power Consumption Approx. 30W
Table 3.1-2 Specifications of the power supply to the DISPLAY PANEL SDN-DP12
