16.Connection with PLC or other Device
16-２
16.1 Outline

SDN-DPH Display Panel has two or three serial ports for connecting with PLC or other devices.
ITEM SPECIFICATIONS
Applicable
Standards
RS-232C, RS-485 (2-wire connection)
Synchronization Asynchronous type
Data Length 7- or 8-bit
Parity None, odd, even
Stop Bit 1- or 2-bit
Baud Rate 4800, 9600, 19200, 38400, 57600, 76800, 115k bps
Modular jack,
8-pin
(MJ1)
Applications Screen data transfer, PLC, temperature controller, CREC, barcode
reader, V-I/O, multi-link2, V-Link, Farm ware transfer for the Display
Panel, etc.
Applicable
Standards
RS-232C, RS-485 (2-wire connection), RS-422（4-wire connection,
SDN-DP06 only）
Synchronization Asynchronous type
Data Length 7- or 8-bit
Parity None, odd, even
Stop Bit 1- or 2-bit
Baud Rate 4800, 9600, 19200, 38400, 57600, 76800, 115k bps
Modular jack,
8-pin
(MJ2)
Applications PLC, temperature controller, CREC, barcode reader, V-I/O,
multi-link2, V-Link, etc.
Applicable
Standards
RS-232C, RS-422/485
Synchronization Asynchronous type
Data Length 7- or 8-bit
Parity None, odd, even
Stop Bit 1- or 2-bit
Baud Rate 4800, 9600, 19200, 38400, 57600, 76800, 115k bps
D-Sub
connector,
9-pin
(CN1)
(SDN-DP12
only)
Applications PLC, temperature controller, CREC, barcode reader, V-I/O,
multi-link2, V-Link, etc.
Table 16.1-1 INTERFACE SPECIFICATION of SERIAL PORT
Refer to the ‘V8 Series Connection Manual’ for the devices to be able to connect, details of each port,
wiring, etc.









