17.NR Data Out Function
17-６
17.1.4 Data Output Timing
 Output timing of receive data can be confirmed by I/O memory I/O7 0E0 - 0E2.
In case of Type S, each bit of I/O7 0E0-0E1 shall be monitored.
In case of Type M, Multi-Controller output bit I/O7 0E2-0 shall be monitored.
●Type S
b15 b14 b13 b12 b11 b10 b9 b8 b7 b6 b5 b4 b3 b2 b1 b0
I/O7:0E0 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1
I/O7:0E1 32 31 30 29 28 27 26 25 24 23 22 21 20 19 18 17
※Number (1 - 32) shows DR No.
Figure 17.1-6 DR Data Output Timing confirm bit
●Type M
b15 〜 b1 b0
I/O7:0E2 - ○
Figure 17.1-7 MC Data Output Timing confirm bit
