7. DATA DISPLAY mode
7-2
7.1 About the DATA DISPLAY mode
The End of Cycle Data such as the tightening peak torque, cycle time, etc. for a single spindle or multiple
spindles are displayed in single display mode (3 items for Type S or 2 items for Type M) or multiple display
mode (1 or 2 items).
Condition 1)： The last selected mode before powering off was the DATA DISPLAY mode.
Condition 2)： The last selected mode before powering off was the SINGLE DISPLAY mode.
Figure 7.1-1 DISPLAY PANEL indication after powering on
SINGL E
D ISPLAY mode
8 SPINDLES
DISPLAY
MODE
4 SPINDLES
DISPLAY
MODE
2 SPINDLES
DISPLAY
MODE
Power on
（NR mode）
No
Yes
Yes
Yes
Condition 1)
MAIN ME NU
DAT A D IS PLAY mod e
Condition 2)
MULTIPLE DISPLAY MODE
16 SPINDL ES
DISPLAY
MODE
32 SPINDL ES
DISPLAY
MODE
