Sanyo SDNR - Operation Flow

4. Operation outline
4-2
4.1 Operation flow
 Operation flow from a start-up to the mode selection is shown as below.
No
 Yes
Yes
No
Condition 1)： NR is selected with initial mode SW.
Condition 2)： DISPLAY PANEL was in DATA DISPLAY mode when power was turned off.
Figure 4.1-1 Operation flow
Condition 1)
Condition 2)
Power ON
MAIN MENU
・ MAINTENANCE
・ TORQUE CURVE
・ FASTENING SETTING
・ RESTART
DATA DISPLAY CONFIGURATION
PASSWORD
LANGUAGE
Receive Data Setting
Init Mode Setting
COM.CONFIGURATION
User Mode
