DISPLAY PANEL MANUAL
13-3
ITEM SPECIFICATION
MODEL SDN-DP12T
DISPLAY DEVICE TFT color
COLOR 65,536 colors (without blinks) / 32,768 colors (with blinks)
DISPLAY RESOLUTION 800 x 600 dots
DIMENSIONS （mm） （W）326.4 x （H）259.6 x （D）87.2
WEIGHT Approx. 2.9 Kg
POWER CONSUMPTION Approx. 30 W
NR INTERFACE ARCNET
Ambient temperature From 0 to 50℃
Humidity 85%RH or less （non-condensing）
Storage temperature From -10 to +60℃
Storage humidity 85%RH or less （non-condensing）
Altitude 2000m or less
Vibration
Resistance
9.8 m/s
2
(1.0G)
Atmosphere No corrosive gas, no excessive dust, and no conductive dust
Cooling system Air cooling without blower
Input voltage DC24V (From 21.6V to 26.4V)
ENVIRONMENTAL CONDITIONS
Noise 1500Vp-p (normal mode, common mode)
Table 13.1-2 DISPLAY PANEL SPECIFICATION(SDN-DP12)
