6. FASTENING SETTING mode (Type M)
6-20
a. BAUD RATE
The baud rate is set.
BAUD RATE (Kbps ) CONTENTS
4.8 RS232C COMMUNICATION BAUD RATE is 4.8Kbps.
9.6 RS232C COMMUNICATION BAUD RATE is 9.6Kbps.
14.4 RS232C COMMUNICATION BAUD RATE is 14.4Kbps.
19.2 RS232C COMMUNICATION BAUD RATE is 19.2Kbps.
28.8 RS232C COMMUNICATION BAUD RATE is 28.8Kbps.
31.2 RS232C COMMUNICATION BAUD RATE is 31.2Kbps.
38.4 RS232C COMMUNICATION BAUD RATE is 38.4Kbps.
Table 6.8-1 COMMUNICATION BAUD RATE
b. STOP BIT
The stop bit is selected to be either 1 stop bit or 2 stop bits.
STOP BIT CONTENTS
1 bit The stop bit is 1.
2 bits The stop bit is 2.
Table 6.8-2 STOP BIT
c. PARITY
The party bit is selected to be EVEN or ODD.
PARITY CONTENTS
EVEN The parity signal is EVEN.
ODD The parity signal is ODD.
Table 6.8-3 PARITY
d. PARITY USAGE
The parity usage is set DISABLE or ENABLE.
PARITY USAGE CONTENTS
DISABLE The parity signal is disabled.
ENABLE The parity signal is enabled.
Table 6.8-4 PARITY USAGE
