6. FASTENING SETTING mode (Type M)
6-24
a. OUTPUT ITEM from 1 to 4
The output of DATA ITEM (from 1 to 4) selected from the DATA OUTPUT setting menu is set as
disabled or enabled. The data form is ASCII.
OUTPUT ITEM from
1 to 4
CONTENTS
OFF The DATA output is disabled.
ON The DATA output is enabled.
Table 6.8-10 DATA OUTPUT
b. COUNT
The COUNT UP output selected from the COMMON SETTING menu is set as disabled or enabled.
COUNT CONTENTS
OFF The COUNT UP output is disabled.
ON The COUNT UP output is enabled.
Table 6.8-11 COUNT
c. ID No.
The SERIAL No. output is set as disabled or enabled.
SERIAL No. CONTENTS
OFF The SERIAL No. output is disabled.
ON The SERIAL No. output is enabled.
Table 6.8-12 SERIAL No.
d. OUTPUT CONDITION
The output of the above items a, b and c are set as an output after fastening cycle or an output
after the external input signal.
OUTPUT CONDITION CONTENTS
AUTO It is outputted after completion of the fastening cycle.
EXIN It is outputted with external input signal.
Table 6.8-13 OUTPUT CONDITION
e. OUTPUT(PRINT)
The output of the above items a, b and c are set as disabled or enabled.
PRINT CONTENTS
OFF The output is disabled.
ON The output is enabled.
Table 6.8-14 OUTPUT
