DISPLAY PANEL MANUAL
7-5
 The following data can be displayed in the SINGLE DISPLAY mode.
ITEM CONTENTS
NR ** JUDGEMENT
The end of cycle status for each NUTRUNNER is displayed and a
status lamp on the DRIVER indicates the judgment result.
SELECT
The program No. (left) and parameter No. (right) are displayed at
the start or at the end of fastening operation.
MESSAGE
The message is displayed when NG or TROUBLE occurs in the
selected DRIVER.
No message is displayed when the judgment is OK.
DISPLAY DATA 1
The data selected as the DISPLAY ITEM 1 is displayed.
(Refer to the Figure7.5-1)
DISPLAY DATA 2
The data selected as the DISPLAY ITEM 2 is displayed.
(Refer to tigure7.5-1)
DISPLAY DATA 3
The data selected as the DISPLAY ITEM 3 is displayed.
(Refer to the Figure7.5-1)
Table 7.3-1 Display data of the SINGLE DISPLAY mode (Type S)
ITEM CONTENTS
GENERAL JUDGMENT
The end of cycle status for all connected spindles is displayed and
a status lamp on the MULTI CONTROLLER indicates the
judgment result.
NR JUDGMENT
The end of cycle status for single NUTRUNNER is displayed and a
status lamp on the DRIVER indicates the judgment result.
SELECT (1)
The program No. (left) and parameter No. (right) are displayed at
the start of fastening operation.
SELECT (2)
The program No. (left) and parameter No. (right) are displayed at
the end of fastening operation.
MESSAGE (1)
The message is displayed when NG or TROUBLE occurs in the
MULTI CONTROLLER.
No message is displayed when the judgment is OK.
MESSAGE (2)
The message is displayed when NG or TROUBLE occurs in the
DRIVER.
No message is displayed when the judgment is OK.
DISPLAY DATA 1
The data selected as a DISPLAY ITEM 1 are displayed.
(Refer to the Figure7.5-1)
DISPLAY DATA 2
The data selected as a DISPLAY ITEM 2 are displayed.
(Refer to the Figure7.5-1)
Table 7.3-2 Display data of the SINGLE DISPLAY mode (Type M)
