8. MAINTENANCE mode
8-6
 The output value of the torque transducer after the calibration is shown in the table below.
MODEL
CALIBRATION
VALUE
(N.m)
CALIBRATION
VALUE
(Kgf.m)
CALIBRATION
VALUE
(ft.lb)
SDNR(T＊1)-005
(On developing)
5.000 0.5098 3.695
SDNR(T＊1)-010,010H 10.00 1.020 7.389
SDNR(T＊1)-025 25.00 2.549 18.47
SDNR(T＊1)-050
SDNR(T＊2)-050
50.00 5.098 36.95
SDNR(T＊2)-100 100.0 10.20 73.89
SDNR(T＊2)-180
SDNR(T＊3)-180
180.0 18.35 133.0
SDNR(T＊3)-320 320.0 32.63 236.5
SDNR(T＊3)-580 580.0 59.14 428.6
SDNR(T＊3)-1000 1000 102.0 738.9
SDNR(T＊3)-1800 1800 183.5 1330
Table 8.2-1 T/T CALIBRATION DATA
  Symbol （＊） indicates [S] in TYPE S and [M] in TYPE M.
CAUTION
Perform the calibration check when the T/T is free from any type of load. Failure to do this will
result in an incorrect calibration value.
WARNING
1. Do not unplug the T/T cable while the T/T calibration check is being performed.
2. If the calibration value deviates more than ±2%, then there is the problem with either the
torque transducer or the T/T cable. Stop the operation immediately and investigate the cause.
