16.Connection with PLC or other Device
16-１２
0C0-0FF
Address CONTENTS Data Format
0C0 - 0D7 MC Receive Data Item （48byte = 24word） Binary
0D8 Receive Data Item 1 Data No. Binary
0D9 Receive Data Item 2 Data No. Binary
0DA Receive Data Item 3 Data No. Binary
0DB Receive Data Item 4 Data No. Binary
0DC Receive Data Item 5 Data No. Binary
0DD Receive Data Item 6 Data No. Binary
0DE-0DE Not used
0E0 NR1 - 16 Data set status 16 bit
0E1 NR17 - 32 Data set status 16 bit
0E2 MC Data set status 1 bit
0E3 - 0E7 Not used
0E8 Receive Data Item 7 Data No. Binary
0E9 Receive Data Item 8 Data No. Binary
0EA Receive Data Item 9 Data No. Binary
0EB Receive Data Item 10 Data No. Binary
0EC Receive Data Item 11 Data No. Binary
0ED Receive Data Item 12 Data No. Binary
0EE - 0EF Not used
0F0 Current Screen No. Binary
0F1 NR mode Screen No. memorized Binary
0F2 Touch Panel – ARCNET unit Online 1 bit
0F3 NR1 - 16 Data Receive mode Online 16 bit
0F4 NR17 – 32 Data Receive mode Online 16 bit
0F5 MC Data Receive mode Online 1 bit
0F6 - 0FF Not used
Figure 16.3-9 I/O7 memory detail (3/3)





