Sanyo SDNR - Page 249

DISPLAY PANEL MANUAL
17-３

CONTENTS TYPE SIGN CODE
JUDGMENT
HEX No
＊＊＊＊
UPPER NG BIT 1/2, LOWER NG BIT 1/2 HEX No ＊＊＊＊
STEP No.
BIN No
＊＊＊＊
CYCLE TIME
BIN No
＊＊＊．＊
OFFSET TORQUE BIN Provided Refer to Table 17.1-2
CYCLE PEAK TORQUE CW BIN Provided Refer to Table 17.1-2
CYCLE PEAK TORQUE CCW BIN Provided Refer to Table 17.1-2
TIGHTENING PEAK TORQUE BIN Provided Refer to Table 17.1-2
NEGATIVE PEAK TORQUE BIN Provided Refer to Table 17.1-2
CYCLE PEAK CURRENT
BIN No
＊＊．＊＊
TIGHTENING PEAK CURRENT
BIN No
＊＊．＊＊
FINAL TORQUE BIN Provided Refer to Table 17.1-2
TIGHTENING TIME
BIN No
＊＊＊．＊
TIGHTENING ANGLE BIN No Refer to Table 17.1-3
FINAL CURRENT
BIN No
＊＊．＊＊
SEATING TORQUE BIN Provided Refer to Table 17.1-2
SEATING TIME
BIN No
＊＊＊．＊
SEATING ANGLE
BIN No
＊＊＊．＊
SNUG TORQUE BIN Provided Refer to Table 17.1-2
SNUG TIME
BIN No
＊＊＊．＊
SNUG ANGLE BIN No Refer to Table 17.1-3
MONITOR ANGLE BIN No Refer to Table 17.1-3
MINIMUM VALUE OF SLOPE 1 BIN Provided Refer to Table 17.1-2
MAXIMUM VALUE OF SLOPE 1 BIN Provided Refer to Table 17.1-2
MINIMUM VALUE OF SLOPE 2 BIN Provided Refer to Table 17.1-2
MAXMUM VALUE OF SLOPE 2 BIN Provided Refer to Table 17.1-2
F (FINAL) SLOPE TORQUE BIN Provided Refer to Table 17.1-2
YIELD POINT ANGLE BIN No Refer to Table 17.1-3
STRETCH ANGLE BIN No Refer to Table 17.1-3
SLOPE BASE VALUE BIN Provided Refer to Table 17.1-2
SLOPE BASE ANGLE BIN No Refer to Table 17.1-3
SLOPE BASE TORQUE BIN Provided Refer to Table 17.1-2
MINIMUM VALUE OF SLOPE 3 BIN Provided Refer to Table 17.1-2
MAXIMUM VALUE OF SLOPE 3 BIN Provided Refer to Table 17.1-2
MID.POINT JUDGEMENT TORQUE BIN Provided Refer to Table 17.1-2
MID.POINT JUDGEMENT TIGHTENING
ANGLE
BIN No Refer to Table 17.1-3
RUN DOWN ANGLE
BIN No
＊＊＊．＊
RUN DOWN TORQUE MINIMUM
JUDGEMENT ANGLE
BIN No
＊＊＊．＊
RUN DOWN TORQUE MAXIMUM
JUDGEMENT ANGLE
BIN No
＊＊＊．＊
TORQUE GAIN CORRECTION
BIN No
＊＊．＊＊
TORQUE OFFSET CORRECTION BIN Provided Refer to Table 17.1-2
ANGLE GAIN CORRECTION
BIN No
＊＊．＊＊
ANGLE OFFSET CORRECTION BIN No Refer to Table 17.1-3
PROGRAM No. PARAMETER No.
HEX No
＊＊＊＊
Figure 17.1-1 Data attribute

