DISPLAY PANEL MANUAL
2-5
NAME FUNCTION
Display Dot matrix of the 800 x 600 dots LCD module use
Power Lamp
Illuminates in green when the Touch Panel is powered on
and is operating normally. When an error occurs to the
backlight (burned-
out backlight, etc.), the power lamp will
flash.
ARCNET 4P modular jack
connector
The RS485 connector to communicate with the DRIVER
Power supply terminal block DC 24V power supply terminal block
DIP switch
#1
Used for setting the terminating resistors of the
RS-422/RS-485 signal line for the MJ1/MJ2.
Slide switch
#1
Used for switching between the RS-232C and RS-422 ports
for the MJ2.
Slide the switch up for RS-232C/RS-485 signals, or slide it
down for RS-422 signals.
D-sub connector Used for connection with PLCs or other peripheral devices.
Modular jack 1 (MJ1)
Used for screen data transfer and connection with PLCs or
other peripheral devices.
Modular jack 2 (MJ2) Used for connection with PLCs or other peripheral devices.
USB-A (master port) Used for printer, CF card reader writer, USB-HUB.
USB-B (slave port)
Used for screen data transfer or connection with a Pict
Bridge-compatible printer.
CF Card Interface Compliant with Compact Flash TM
Table 2.1-2 SDN-DP12 Names and functions
# The DISPLAY PANEL is compatible with V812 series of Hakko Electronics. Refer to “V8 Series Hardware
Specifications” for detail.
