5. FASTENING SETTING mode (Type S)
5-6
a. Torque unit
The unit of torque to be used is selected.
Table 5.2-2 Torque Unit
b. Emergency stop contacts
[Normally open] or [Normally close] of the contacts is selected for the emergency stop input for the
DRIVER I/O interface.
Table 5.2-3 Emergency stop contacts
c. Data output format
The format of the output data is set.
Table 5.2-4 Data output format
d. Input Filter
The input filter of the Driver’s input interface is set.
Table 5.2-5 Input filter
Torque unit CONTENTS
kgf.m The torque unit is “ kgf.m “
N.m The torque unit is “ N.m “
Ft.lb The torque unit is “ ft.lb “
Emergency stop CONTENTS
N. O.
Normally open contact is selected for emergency stop input.
Closing contact activates the Emergency stop.
N. C.
Normally close contact is selected for emergency stop input.
Opening contact activates the Emergency stop.
Data output format CONTENTS
BCD The format of the output data is BCD.
BIN The format of the output data is BIN.
Input Filter CONTENTS
NORMAL Input filter : Normal
SMALL Input filter : Small (50% of Normal)
