5. FASTENING SETTING mode (Type S)
5-12
a. Monitor output items
The monitor items are shown as below.
Monitor output item CONTENTS
ANGLE The angle is outputted in the real time.
TIGHTENING ANGLE The tightening angle is outputted in the real time
TORQUE The torque is outputted in the real time.
SPEED The speed is outputted in the real time.
ELECTRIC CURRENT The electric current is outputted in the real time
Table 5.2-9 Monitor terminal item
b. Monitor output gain
The terminal for the gain output is set.
Recommended setting (Default value) = 0004h
c. Monitor output offset
The terminal for the offset output is set.
Recommended setting (Default value) = 022Ch
To Next Page
