Communications Interfaces
Communications Card
The ANALOGS region contains protection and automation variables. This
region is updated every 0.5 seconds. See Table 4.26 for the Map.
The STATE region contains elements defined with the SET R command and
an attached SOE queue that holds up to 100 records. The relay updates this
region within 0.5 seconds of any new events. Communications card protocols
that require state changes with SOE-quality timestamps must retrieve this data
from the STATE region. See Table 4.27 for the Map. See DNP LAN/WAN
Application Example on page R.6.49 for DNP LAN/WAN implementation
details.
The communications card database is virtual device 1 in the relay. You can
display the contents of a region using the MAP 1:region command (where
region is one of the database region names listed in Table 4.18). An example
of the MAP command is shown in Figure 4.4.
602B PS_WARN char[8] Power supply warning string
6033 PS_FAIL char[8] Power supply failure string
603B HW_FAIL char[40] Hardware failure strings
6063 CC_STA char[40] Comm. card status strings
608B PORT_STA char[160] Serial port status strings
612B TIME_SRC char[10] Time source
6135 LOG_ERR char[40] SEL
OGIC error strings
615D TEST_MD char[160] Test mode string
Table 4.26 SEL-421 Communications Card Database Structure—ANALOGS
Region
Address
(Hex)
Name Type Description
7000 _YEAR int 4-digit year when data was sampled
7001 DAY_OF_YEAR int 1–366 day when data was sampled
7002 TIME(ms) long int Time of day in msec when data was sampled
(0–86400000)
7004 PMV01_64 float[64] PMV01–PMV64
7084 AMV001_256 float[256] AMV001–AMV256
Table 4.27 SEL-421 Communications Card Database Structure—STATE Region
Address
(Hex)
Name Type Description
8000 _YEAR int 4-digit year when data was updated
8001 DAY_OF_YEAR int 1–366 day when data was updated
8002 TIME(ms) long int Time of day in msec when data was updated
(0–86,400,00)
8004 ELEMENTS int[16] 250 Relay Word bits defined to be SER points;
SER point 1 goes in first register bit 0,...
8014 CARD_SER int[8] 128 Relay Word bits defined to be SER points
from R CC settings.
Table 4.25 SEL-421 Communications Card Database Structure—STATUS Region
(Sheet 2 of 2)
Address
(Hex)
Name Type Description
