R.6.18
SEL-421 Relay Reference Manual Date Code 20111215
DNP3 Communications
DNP3 Documentation
10, 12 38 Reset energies
10, 12 39 Reset breaker monitor
10, 12 40 Reset front panel targets
10, 12 41 Read next relay event
10, 12 42 Reset min/max metering
10, 12 43 Reserved
10, 12 44–59 Remote bits RB17–RB32
10, 12 60–67 Remote bit pairs RB17–RB32
20, 22 00 Active settings group
20, 22 01 Reserved
20, 22 02 Reserved
20, 22 03 Number of unread event reports
20, 22 04 Number of breaker operations on Circuit Breaker 1 A-phase
20, 22 05 Number of breaker operations on Circuit Breaker 1 B-phase
20, 22 06 Number of breaker operations on Circuit Breaker 1 C-phase
20, 22 07 Number of breaker operations on Circuit Breaker 2 A-phase
20, 22 08 Number of breaker operations on Circuit Breaker 2 B-phase
20, 22 09 Number of breaker operations on Circuit Breaker 2 C-phase
30, 32 00, 01
a
Line A-phase current magnitude (amps) and angle (LIAFM, LIAFA)
b
30, 32 02, 03
a
Line B-phase current magnitude (amps) and angle (LIBFM, LIBFA)
b
30, 32 04, 05
a
Line C-phase current magnitude (amps) and angle (LICFM, LICFA)
b
30, 32 06, 07 Reserved
30, 32 08, 09
a
Circuit Breaker 1 A-phase current magnitude (amps) and angle (B1IAFM, B1IAFA)
b
30, 32 10, 11
a
Circuit Breaker 1 B-phase current magnitude (amps) and angle (B1IBFM, B1IBFA)
b
30, 32 12, 13
a
Circuit Breaker 1 C-phase current magnitude (amps) and angle (B1ICFM, B1ICFA)
b
30, 32 14, 15 Reserved
30, 32 16, 17
a
Circuit Breaker 2 A-phase current magnitude (amps) and angle (B2IAFM, B2IAFA)
b
30, 32 18, 19
a
Circuit Breaker 2 B-phase current magnitude (amps) and angle (B2IBFM, B2IBFA)
b
30, 32 20, 21
a
Circuit Breaker 2 C-phase current magnitude (amps) and angle (B2ICFM, B2ICFA)
b
30, 32 22–35 Reserved
30, 32 36, 37
c
Line A-phase voltage magnitude (kV) and angle (VAFM, VAFA)
b
30, 32 38, 39
c
Line B-phase voltage magnitude (kV) and angle (VBFM, VBFA)
b
30, 32 40, 41
c
Line C-phase voltage magnitude (kV) and angle (VCFM, VCFA)
b
30, 32 42
c
Polarizing voltage magnitude (volts) (VPM)
b
30, 32 43 Reserved
30, 32 44
c
Synchronizing voltage 1 magnitude (volts) (NVS1M)
b
30, 32 45 Reserved
30, 32 46
c
Synchronizing voltage 2 magnitude (volts) (NVS2M)
b
30, 32 47 Reserved
30, 32 48, 49
a
Line zero-sequence current magnitude (3I0) in amps and angle (LIGM, LIGA)
b
30, 32 50, 51
a
Line positive-sequence current magnitude in amps and angle (LI1M, LI1A)
b
Tabl e 6 . 10 SEL -42 1 DNP3 Default Data Map (Sheet 2 of 4)
Object Indices Description
