Date Code 20111215 Reference Manual SEL-421 Relay
DNP3 Communications
Application Example
(Continued from previous page)
9:
? 607 <Enter>
10:
? <Enter>
Binary Output Map
(Index Number)
1:
? 0 <Enter>
2:
? 1 <Enter>
3:
? 2 <Enter>
4:
? 3 <Enter>
5:
? 4 <Enter>
6:
? 5 <Enter>
7:
? 32 <Enter>
8:
? <Enter>
Analog Input Map
(Index Number, Scale Factor, Deadband)
1:
? 0 <Enter>
2:
? 1,1,200 <Enter>
3:
? 2 <Enter>
4:
? 3,1,200 <Enter>
5:
? 4 <Enter>
6:
? 5,1,200 <Enter>
7:
? 36 <Enter>
8:
? 37,1,200 <Enter>
9:
? 38 <Enter>
10:
? 39,1,200 <Enter>
11:
? 40 <Enter>
12:
? 41,1,200 <Enter>
13:
? 87,40,40<Enter>
14:
? 91,40,40 <Enter>
15:
? 100,,200 <Enter>
16:
? <Enter>
Analog Output Map
(Index Number)
1:
? 0 <Enter>
2:
? <Enter>
DNP
DNP Object Default Map Enables
DNPBID := N DNPBOD := N DNPCOD := Y DNPAID := N
DNPAOD := Y
Binary Input Map
(Index Number)
1: 7
2: 6
3: 1024
4: 1025
5: 1026
6: 1027
(Continued on next page)
